DF10P-C2-K-L Dimmer Switch, 120 V, 1200 W, 3-Way
Sku: 5175500-052303-18
$40.99
4 Available at
SHIP TO STORE
Eaton's wiring devices offers code-compliant, commercial lighting control devices that combines dimming technology and energy savings while helping to reduce installation costs for your commercial buildings. Our 0 to 10V decorator dimmer integrates full-slide control for easy, precise operation allowing the user to return to previous light level turning lights ON.
- Preset feature allows user to return to previous light or fan setting when turning lights on
- Integrated full-slide control for easy, precise operation
- Neutral is not required for installation of device
- Adjustable high-level trim setting for optimal lamp compatibility
- Faceplate is removable to allow for color changes
- Electrostatic discharge protection
- Compatible with any decorator wallplate or screwless decorator wallplate
- Compatible with dimmable LED and fluorescent 0 to 10 V ballasts
Voltage Rating
120
Frequency Rating
60
Wattage Rating
1200
Number of Poles
1
Operation Modes
3-Way
Terminal Type
Back, Side
Temperature Rating
-4 to 158
Material
Polycarbonate
Dimensions
1.8 in L x 1.29 in W x 4.2 in H
