SET-3G SET3G10 High-Strength Epoxy Adhesive, 8.5 oz Cartridge, Coaxial Cartridge
Sku: 12235010
$38.99
18 Available at
San Marcos
Location:
Aisle 4
SET-3G is an epoxy-based anchoring adhesive with high design strength and proven performance. SET-3G is a 1:1 ratio, two-component, anchoring adhesive for concrete (cracked and uncracked). SET-3G installs and performs in a variety of environmental conditions and temperature extremes.
- Excellent bond strengths permit ductile solutions in high seismic areas
- Recognized per ICC-ES AC308 for post-installed rebar development and splice length design provisions
- Improved sustained load performance at elevated temperature
- Can be specified for all base material conditions when in-service temperatures range from -40 to 176 deg F
- Manufactured in the USA using global materials
- 8.5 oz coaxial cartridge
- Wire brush hole-cleaning system for conventional blow-brush-blow cleaning method for anchoring
- With higher bond strengths, ductile solutions can often be achieved with SET-3G in high seismic areas
- Low-odor formulation
- For use with potable water
Cartridge Type
Coaxial
Cartridge Size
8.5
Color
Gray
VOC Content
1.9
Curing Time
192
Mixing Ratio
1:1
Temperature Rating
-40 to 176
Includes
(2) EMN22i Mixing Nozzles and (2) Nozzle Extensions
