BD2020 Circuit Breaker with Rejection Tab, Duplex, Type BD, 20 Amp, 1 -Pole, 120 V, Instantaneous Trip
Sku: 18039726
$22.99
5 Available at
San Marcos
Location:
Aisle 26
BD Eaton Circuit Breaker Options:BD2020 20 Amp, 1 Pole
Switching duty rating, duplex type breaker requires 1 in per breaker. Thermal magnetic 40 deg C breakers have rejection tab feature, allows only 42 circuits in the panel in compliance with NEC article 384-15. Interchangeable will replace Bryant, Challenger and Westinghouse. Type BR 120/240 V. 10,000 AIR. 1 in per breaker.
- They contain either a main breaker when used at the service entrance point or a main lug when used as a sub-panel to add circuits to existing service.
- The main breaker protects the main entire panel and can be used as a service disconnect
- Loadcenters are enclosures specifically designed to house the branch circuit breakers and wiring required to distribute power to individual circuits.
Type
Duplex, Type BD
Voltage Rating
120
Current Rating
20
Operating Frequency
50/60
Number of Phases
1
Number of Poles
1
Interrupt Rating
10
Actuator Type
Magnetic, Thermal
Trip Type
Instantaneous
Wire Size
14 to 4
Terminal Type
Feed-Thru
Number of Spaces
1
Mounting Type
Plug
Dimensions
3.1 in L x 0.98 in W x 2.89 in H
Operating Temperature
40
Suitable for
Overload and Short Circuit Protection of Home Electrical System
