Eaton Wiring Devices

BP3867-4RN Electrical Plug, 2 -Pole, 15 A, 125 V, NEMA: NEMA 5-15, Fluorescent Orange

Sku: 18260322
$7.49
5 Available at San Marcos
Location: Aisle 25

Highly visible and easy to locate at the job sight. Molded out of impact-and chemical-resistant nylon. Neoprene gasket seals cord opening to protect against moisture, dirt, wood chips and more. Temperature rating of -40 to 75 deg C. 15 A. UL 498 listed (file #E15012), CSA Certified C22.2 #42 (file #2081) (6221-02) NOM Certified. NEMA 5-15. Carded.

  • Solid brass plug blades are firmly embedded in body
  • Terminal screw clamps are designed to contain wire and prevent binding
  • Terminal screws backed out ready for wiring
  • High visibility products for quick location and identification of plugs in the middle of a job site
  • High visibility product contains neoprene dust cover which prevents dust from entering the plug or connector at the cable entrance
  • Combination Slotted/Phillips head mounting and terminal screws ease installation with power screwdrivers

Type
High-Visibility, Straight
Voltage Rating
125
Current Rating
15
Number of Poles
2
Number of Wires
3
Cable/Wire Size
1/4 to 21/32
Grounding Type
Grounded
Operating Temperature
-40 to 75
Material
Nylon
Color
Fluorescent Orange
Dimensions
1.83 in L x 1.52 in W
NEMA Configuration
NEMA 5-15
