4509AN-BOX Electrical Plug, Angled, Straight Body, 1/4 to 21/32 in, 2-Pole, 20 A, 250 V, Yellow
Sku: 6088470-052303-18
$13.47
103 Available at
SHIP TO STORE
Estimated Arrival On: 12/11/2025
Solid brass plug blades are firmly embedded in body. Resists chemical attack and is less brittle in extremely low temperatures. With terminal screw clamps. Combination Slot/Phillips head mounting and terminal screws for installation flexibility (Slot/Robertson screws in Canada where available). Terminal screws backed out, ready for wiring. Yellow color. Meets all UL 498 requirements.
- Solid brass plug blades are firmly embedded in body
- Vinyl plugs and connectors resist chemical attack and are less brittle in extremely low temperatures
- Terminal screws backed out ready for wiring
- Terminals in individual chambers to positively insulate conductors
- Terminal screw clamps are designed to contain wire and prevent binding
- Combination Slotted/Phillips head mounting and terminal screws ease installation with power screwdrivers
- Vinyl angle plugs have eight possible positions for maximum convenience
Type
Angled, Straight Body
Voltage Rating
250
Current Rating
20
Number of Poles
2
Number of Wires
3
Cable/Wire Size
1/4 to 21/32
Grounding Type
Grounded
Operating Temperature
-20 to 60
Mounting Type
Screw
Material
Thermoplastic/Vinyl
Color
Yellow
Dimensions
1-61/64 in L x 1-1/2 in W x 1-27/64 in D
NEMA Configuration
NEMA 6-20
