4882-BOX Electrical Connector, 2-Pole, 15 A, 125 V, Screw, NEMA: NEMA 1-15, Yellow
Sku: 6449490-052303-18
$5.44
45 Available at
SHIP TO STORE
Estimated Arrival On: 04/16/2026
Commercial-grade vinyl connectors solid brass plug blades are firmly embedded in body. Terminal screw clamps are designed to contain wire and prevent binding. Terminal screws backed out-ready for wiring. Terminals in individual chambers to positively insulate conductors. Combination slot/Phillips head mounting and terminal screws ease installation with power screwdrivers.
- Solid brass plug blades are firmly embedded in body
- Terminal screw clamps are designed to contain wire and prevent binding
- Terminal screws backed out ready for wiring
- Terminals in individual chambers to positively insulate conductors
- Thermoplastic rubber plugs and connectors maintain flexibility in extremely low temperatures
- Combination Slotted/Phillips head mounting and terminal screws ease installation with power screwdrivers
Type
Straight Blade
Voltage Rating
125
Current Rating
15
Number of Poles
2
Number of Wires
2
Cable/Wire Size
1/4 to 21/32
Connection Type
Screw
Grounding Type
Non-Grounded
Operating Temperature
-20 to 60
Material
Vinyl
Color
Yellow
Dimensions
2.61 in L x 1.54 in W
NEMA Configuration
NEMA 1-15
