Bussmann

SC Series SC-25 Fuse, 25 A, 480 VAC, 300 VDC, 100 kA Interrupt, Melamine Body, G, Low Voltage, Time Delay Fuse

Product SKU #0951319-052303-18
Shop the brand
$19 .98
Ship to Store
18 As soon as 09/17
Delivery
18 As soon as 09/17
Free Pickup at San Marcos
18 SHIP TO STORE Check other stores
Members get savings and rewards! Sign in or join for FREE

Free & Easy Returns in Store

They have a minimum 300 V rating and are available up to 60 A. All SC fuses are 13/32 in Dia with varying lengths to provide a rejection feature that helps prevent over fusing (installing a 30 A fuse in a 20 A circuit). One half to 6 A SC fuses are fast-acting, while 7 to 60 A SC fuses are time delay to permit temporary overloads to pass without nuisance openings.

  • Most economical overcurrent protection solution compared to circuit breakers
  • For use in various non-demanding, general purpose applications
  • Most economical over current protection solution compared to circuit breakers

Voltage Rating
480 VAC, 300 VDC
Current Rating
25
Interrupt Rating
100
Fuse Type
Low Voltage, Time Delay
Fuse Group
AJ
Element Type
Dual
Indicator Type
Non-Indicating
Rejection/Non-Rejection
Rejection
Terminal Type
Holder
Body Material
Melamine
Diameter
13/32
Length
1-5/8
