Southwire®

63968205 500 ft. Building Wire, NM-B, 4/3, Black

Product SKU #180132
Shop the brand
$10 .49 / Foot
Ship to Store
Special Order As soon as 10/05
Delivery
Special Order As soon as 10/05
Free Pickup at San Marcos
Special Order SHIP TO STORE Check other stores
Building Wire: Romex 63968205 4 AWG
Romex 63950005 6 AWG Romex 28894401 6 AWG Southwire 63950021 6 AWG Southwire 63950032 6 AWG Romex 63949205 8 AWG Romex 28893601 8 AWG Southwire 63949221 8 AWG Southwire 63949232 8 AWG Southwire 10/2NM-WGX50 10 AWG Romex 28829001 10 AWG Romex 12/2NM-WGX25 12 AWG Southwire 12/3NM-WGX50 12 AWG Romex 28828201 12 AWG Romex 63947601 12 AWG Romex 14/2NM-WGX25 14 AWG Romex 14/3NM-WGX25 14 AWG Romex 14/3NM-WGX50 14 AWG Romex 28827401 14 AWG Southwire WGX1000FT 14 AWG Southwire 10/3NM-WGX50 10 AWG Southwire 6/2NM-WGX125 6 AWG Southwire 6/3NM-WGX125 6 AWG Southwire 8/2NM-WGX125 8 AWG Southwire 8/3NM-WGX125 8 AWG Romex 28829021 10 AWG Romex 28829028 10 AWG Romex 63948421 10 AWG Southwire 10/3NM-WGX100 10 AWG Romex 28829055 10 AWG Romex 63948455 10 AWG Romex 28828222 12 AWG Romex 28828228 12 AWG Romex 63947621 12 AWG Romex 63947628 12 AWG Romex 28828255 12 AWG Romex 63947655 12 AWG Romex 28827422 14 AWG Romex 28827428 14 AWG Romex 63946828 14 AWG Romex 28827455 14 AWG Romex 63946855 14 AWG
Members get savings and rewards! Sign in or join for FREE

Free & Easy Returns in Store

Southwire® SIMpull NM-B (nonmetallic-sheathed) cable may be used for both exposed and concealed work in normally dry locations at temperatures not to exceed 90 deg C (with ampacity limited to that for 60 deg C conductors) as specified in the National Electrical Code. NM-B cable is primarily used in residential wiring as branch circuits for outlets, switches and other loads. NM-B cable may be run in air voids of masonry block or tile walls where such walls are not wet or damp locations. Voltage rating for NM-B cable is 600 V.

  • SIMpull® jacket designed for easier pulling
  • NM-B cable may be run in air voids of masonry block or tile walls where such walls are not wet or damp locations
  • Color-coded jacket
  • Made in America

Type
NM-B
Wire Size
4
Length
500
Number of Conductors
3
Strands per Conductor
7
Conductor Material
Copper
Conductor Insulation
PVC
Stranded/Solid
Stranded
Sheath Material
Nylon
Sheath Color
Black
Sheath Diameter
825
Voltage Rating
600
Current Rating
70
Operating Temperature
90
Gauge/Conductors
4/3
