Centium Series ICN2S40N Electronic Ballast, 120/277 V, 72 W, 2-Lamp
Sku: 18220018
$31.99
2 Available at
San Marcos
Location:
Aisle 24
Fluorescent Ballasts Options :Philips ICN2S40N Electronic
For use with one or two F30T12, F34T12 or F40T12 bulbs. Minimum start temperature 50 deg. 120 to 277 V. UL and CSA listed.
Voltage Rating
120/277
Current Rating
0.26/0.62
Operating Frequency
50/60
Wattage Rating
72
Circuit Type
Series
Lamp Wattage
40
Number of Lamps
2
Start Type
Rapid
Ballast Factor
0.85
Ignition Time
1
Wire Size
18
Total Harmonic Distortion (THD)
10
Operating Temperature
70
Dimensions
9.5 in L x 1.3 in W x 1 in H
Material
Metal
