1303-7V Toggle Switch, 3 -Pole, 15 A, Wall Mount, Lead Wire Terminal, Ivory
Sku: 4585576-052303-18
$2.46
2307 Available at
SHIP TO STORE
Ivory Toggle Switch Options:Eaton 1303-7V 3Pole, 120 V
Eaton Wiring Devices 1303-7V Toggle Switch, 3 -Pole, 15 A, Wall Mount, Lead Wire Terminal, Ivory
- 3-way switches feature additional push-in common termination for feed-through tapping
- Push-in terminals accept #14 AWG solid wire only, side wire terminals accept up to #10 AWG solid wire
- Long, broad mounting strap virtually eliminates floating installations
- Patented built-in wire stripper for #12 and #14 AWG wire to speed installation
- Tri-combo screws accept Slotted, Phillips and Robertson head tools for installation flexibility
- Wire looper speeds termination of both #14 and #12 AWG wire
Voltage Rating
120
Current Rating
15
Wattage Rating
0.5
Number of Poles
3
Contact Material
Silver
Dielectric Strength
1500
Terminal Type
Lead Wire
Actuator Type
Toggle
Temperature Rating
-20 to 60
Mounting Type
Wall
Housing Material
Polycarbonate
Color
Ivory
Dimensions
4.2 in L x 1.44 in W x 1.103 in D
