CLHB Series CLHB-1-LB3-CP2-MV-LVD High Bay Fixture, 120/277 V, 60, 80, 110 W, LED Lamp, 8400, 15,800 Lumens
Sku: 5347968-052303-21
$135.97
13 Available at
SHIP TO STORE
Estimated Arrival On: 12/26/2025
Each CLHB compact high bay series combines a small profile with great lumen output and has an excellent operating temperature range from 22 to 122 deg F. Luminaires are both CCT and wattage selectable - offering flexibility and efficiency.
- Lightweight iron and aluminum housing designed for durability
- Thermal management - fixture top is designed to maximize heat dissipation
- Frosted polycarbonate lens provides excellent light quality
- 3 ft chain and V-hooks included for suspended-mounting
- 3 Lumen Boost®/2 CCT Color Preference® for easy field adjustable lumen/CCT selection with switch located on back panel
Voltage Rating
120/277
Wattage Rating
60, 80, 110
Lamp Type
LED
Bulb Shape
Linear
Average Life
>95,000
Color Rendering Index (CRI)
80+
Beam Angle
87, 102
Color Temperature
4000, 5000
Lumens
8400, 15,800
Ballast/Driver Type
0 to 10 V Dimmable
Shade Type
Frosted
Shade Material
Polycarbonate
IP Rating
IP20
Temperature Rating
22 to 122
Fixture Material
Aluminum/Iron
Fixture Color
White
Dimensions
23.98 in L x 11.81 in W x 2.13 in H
Hanging Device Length
3
Includes
3 ft Chain and V-Hook
