Wiring Devices BR15W Duplex Receptacle, Nylon/PVC, White, 2-Pole, 15 A, 125 V, Back, Side Wiring, NEMA: 5-15R
Sku: 6088934-052303-18
$4.69
920 Available at
SHIP TO STORE
Estimated Arrival On: 05/02/2026
Commercial-grade straight blade receptacles 15 A, 125 V, NEMA 5-15R. Engineered for safe, reliable performance, these UL 498 and Federal Specification WC-596 listed devices provide maximum durability in a wide variety of applications while providing installation efficiency to help finish the job on time.
- Galvanized steel, wraparound yoke mounting strap for great assembly security, extra length, width helps reach large panel cutouts for code compliance
- Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure and provides redundant measure of ground continuity where jumper is used
- Screw-catch feature on duplex devices speeds mounting of wallplates
- Tamper-resistant receptacles provide compliance with 2014 NEC Article 406.12 that states that all 15 A and 20 A, 125 V receptacles installed in dwelling units must be tamper-resistant
Voltage Rating
125
Current Rating
15
Number of Poles
2
Number of Wires
3
Wiring Type
Back, Side
Wire Size
14 to 10
NEMA Configuration
5-15R
Operating Temperature
-4 to 140
Mounting Type
Flush
Material
Nylon/PVC
Color
White
Dimensions
1.3 in L x 0.88 in W x 4.2 in H
